Fixing tie for hole (oval), ∅1.0-25.0mm, black, 500pcs.
Art.-No. 126-00413 | T30SOS-AS-SFT712S-E-PA66HS-BK |  Details

1-piece fixing ties with arrowhead, with disc for oval holes.

    • Easy to install without the need for a tool
    • Arrowhead simply locks into place
    • Disc adjusts tie for pressures from various directions and minimises access of dust and dirt
    • Cable tie head always situated in a defined position
    • Versions for oval holes feature anti-twist protection
    Show more
    Add to watchlist
    Downloads Datasheet
    Application With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building.
    Colour Black (BK)
    Fixation Method Arrowhead for oval holes
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION T30SOS-AS-SFT712S-E-PA66HS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family for oval holes
    Product Group 1-piece fixing ties with arrowhead, with disc
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T30SOS-AS-SFT712S-E
    Bundle Diameter max (metric) 25.0mm
    Bundle ∅ 1.0-25.0mm
    Bundle ∅ min. 1.0mm
    Fixing Hole Shape Oval
    Length (L) 127.6mm
    Min.Tensile Strength 200N
    Panel Thickness max. 0.6-2.6mm
    Thickness (T) 1.2mm
    Width (W) 3.4mm
    for Hole ∅ (FH) 7.0 x 12.0 mm
    for Panel Thickness min - max 0.6 - 2.6 mm
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026661087
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
    Show all
