Fixing tie for screw fixation, ∅1.5-45.0mm, black, 250pcs.
Art.-No. 156-02682 | T50RDHDM6-2-PA66HS/PA66HIRHS-BK |  Details

DHDM (Double heavy duty mount) for parallel routing of bundles.

    • Pre-assembled 2-piece fixing tie
    • Cable tie head can be moved after bundling
    • Secure alignment to the bundle due to H-design
    • A suitable alternative for metal clamps
    • Withstands vibrations and displacement forces
    • High tightening torque through metal bushing
    Show more
    Add to watchlist
    Downloads Datasheet
    Application Used in the automotive and truck industry for harness fixing in the engine body, these parts offer solutions in many other industrial applications with difficult environment.
    Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
    Colour Black (BK)
    Fixation Method Fixing hole
    Foot Part Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Identification Plate Position none
    Key product features vibration absorbing
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Mounting Screw Type M6 Screw
    PART DESCRIPTION T50RDHDM6-2-PA66HS/PA66HIRHS-BK
    Pack Cont. 250pcs.
    Package Content packed in bag
    Product Family DHDM-Series for parallel routing
    Product Group 2-piece fixing ties for heavy duty applications, for screws
    Tie Closure plastic pawl
    Type T50RDHDM6-2
    Bundle Diameter max (metric) 45.0mm
    Bundle ∅ 1.5-45.0mm
    Bundle ∅ min. 1.5mm
    Length (L) 200.0mm
    Min.Tensile Strength 225N
    Thickness (T) 1.2mm
    Weight/Unit 0.00833kg
    Width (W) 4.6mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    Customs Number 39269097
    GTIN-13 / EAN 4031026621425
    Packaging 1 - Height (m) 0.17m
    Packaging 1 - Length (m) 0.555m
    Packaging 1 - Qty 250
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.03302m³
    Packaging 1 - Weight (kg) 2.146kg
    Packaging 1 - Width (m) 0.35m
    Packaging 3 - Height (m) 0.35m
    Packaging 3 - Length (m) 0.57m
    Packaging 3 - Qty 1000
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0778m³
    Packaging 3 - Weight (kg) 9.58kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.194m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 12000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.146m³
    Packaging 4 - Weight (kg) 135.984kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
