13/11/2024

Fixing tie with pipe/tube holder, inside serrated, ∅45.0mm, black, 2000pcs.
Art.-No. 156-01180 | T50ROC10-14CBTO-SD-SET-PA66HS/PA66HIRHS-BK |  Details

Pipe Clip CBTO, twistable 90°.

    Add to watchlist
    Downloads Datasheet
    Application For post-installation of additional cables for pre-assembled cable looms and variety of twist angles and even different loop directions provide flexibility for cable routing. CBTO-series for cable ties up to 5 mm.
    Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
    Colour Black (BK)
    Fixation Method Omega Clip
    Identification Plate Position none
    Key product features rotatable, for multiple routing, removable
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T50ROC10-14CBTO-SD-SET-PA66HS/PA66HIRHS-BK
    Pack Cont. 2000pcs.
    Package Content packed in box
    Product Group 2-Piece Fixing Ties with Pipe, twistable 90°
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50ROC10-14CBTO-SD-SET
    Variant Inside Serrated
    Attach to Ø 10.0 - 14.0
    Bundle Diameter max (metric) 45.0mm
    Bundle ∅ 45.0mm
    Length (L) 202mm
    Width (W) 4.6mm
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin SG
    GTIN-13 / EAN 4031026474069
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121731
