13/11/2024

Fixing tie for hole (round), inside serrated, ∅1.6-44.5mm, black, 100pcs.
Art.-No. 126-01003 | T50RSF(U)-PA66-BK |  Details

The arrowhead design of this push mount inserts easily and locks securely in place.

    • Easy to assemble without the need for a tool
    • Fixing tie with arrowhead without wings
    • Arrowhead simply locks into place
    • Cable tie head always situated in defined position
    Add to watchlist
    Downloads Datasheet
    Application The arrowhead design is usefull in areas with limited space.
    Colour Black (BK)
    Fixation Method arrowhead
    Identification Plate Position none
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION T50RSF(U)-PA66-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family without wings and disc, for round holes
    Product Group 1-Piece Fixing Ties with Arrowhead
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50RSF(U)
    Variant Inside Serrated
    Bundle Diameter max (metric) 44.5mm
    Bundle ∅ 1.6-44.5mm
    Bundle ∅ min. 1.6mm
    Height (H) 7.50mm
    Length (L) 210.82mm
    Min.Tensile Strength 225N
    Panel Thickness max. 1.0 - 3.56mm
    Thickness (T) 1.2mm
    Width (W) 4.7mm
    for Hole ∅ (FH) 6.4 - 7.1 mm
    for Panel Thickness min - max 1 - 3.6 mm
    for Panel Thickness min - max 0 - 0.1 "
    CE Certification Yes
    CSA Certified No
    Flammability UL 94 V2
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Specifications UL-ZODZ2.E64139
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US and Canada) Yes
    UL Type 11
    UL-File Number E64139
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026415642
    Packaging 3 - Height (m) 0.20955m
    Packaging 3 - Length (m) 0.60801m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0506m³
    Packaging 3 - Width (m) 0.39688m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
