Bottle Shape with External Rib VG-Style for Plugs black, PO-X
Art.-No. 401-99480 | 199-4-G-PO-X-BK |  Details

199-4-G supplied / fully recovered.

    • Specifically for small audio connectors
    • Multiple external ribs to improve grip in harsh conditions
    Add to watchlist
    Downloads CAD-Download
    Application Heat Shrinkable moulded shapes for use in Electrical and Electronic Cable Harness Applications.
    Colour Black (BK)
    Material Polyolefin, cross-linked (PO-X)
    PART DESCRIPTION 199-4-G-PO-X-BK
    Pack Cont. 1pc.
    Package Content packed in pcs.
    Product Family Helashrink 190 Series, with external ribs
    Product Group Bottle Shapes, VG style
    Short Description Bottle Shape with External Rib VG-Style for Plugs black, PO-X
    Type 199-4-G
    Variant For plug
    HW ± 20 % 1.8mm
    JO ± 10 % 20.0mm
    JW ± 20 % 0.5mm
    JW ± 30 % 0.5mm
    P ± 10 % 70.0mm
    R nom. 35.0mm
    R ± 10 % 35.0mm
    S nom. 20.0mm
    T ± 20 % 1.0mm
    V ± 10 % 1.5mm
    V ± 20% 1.5mm
    Weight/Unit 0.004kg
    ∅H max. b 14.0mm
    ∅H min. a 17.5mm
    ∅J max. b 4.3mm
    ∅J min. a 7.0mm
    Designation as per VG-Norm VG 95343 T06 A 010 A
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Min. Shrink Temperature - °C +135 °C
    Nato number 5970-99-555-0035, 5970-12-323-3278
    Operating Temperature -75 °C to +150 °C
    ROHS compliant Yes
    Specifications
    Specifications VG 95343-6
    Tensile Strength 15MPa
    Country of Origin GB
    Customs Number 39174000
    GTIN-13 / EAN 5022660634819
    Packaging 1 - Height (m) 0.025m
    Packaging 1 - Length (m) 0.13m
    Packaging 1 - Qty 1
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00033m³
    Packaging 1 - Weight (kg) 0.004001kg
    Packaging 1 - Width (m) 0.1m
    ETIM 7.0 Key EC002464
    ETIM 8.0 Key EC002464
    ETIM 9.0 Key EC002464
    UNSPSC Key 39121721
