Cable label, self laminating, white/transparent, thermal transfer print, 39.87x31.75mm, H2=134.62mm, 650pcs.
Art.-No. 596-01904 | TAG32-135TD1-1232-CL/WH |  Details

Helatag 1232 – self-laminating labels with good resistance to alcohol and hydraulic oils.

    • High-quality self-laminating labels made of polyester
    • Suitable for marking of wires and cables in harsh environments
    • Flexible but also tear and impact resistant material
    • Excellent resistance to alcohol, gasoline, cleaning agents and hydraulic oils
    • Very temperature and UV-resistant
    • Perforation allows demand-based shortening of the protective laminate for smaller outer diameters
    • Laminating function gives excellent protection against humidity and mechanical abrasion
    • Rounded edge design gives additional bonding strength
    Show more
    Add to watchlist
    Downloads Datasheet e-Learning
    Application These self-laminating labels are ideal for marking hoses and pipes in harsh environments, e.g. as they can be found in the hydraulics industry. Helatag 1232 consists of a white printable area with a protective laminate ensure the printed text is shielded from negative environmental influences - such as humidity, dirt, debris and mechanical abrasion.
    Application Method The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance.
    Cable ∅ max 30.24mm
    Cable ∅ min 14.01mm
    Chem. Material Properties Resistant to water, alcohol, most oils, greases, fuel, aliphatic solvents, weak acids, salts and alkalis.
    Colour White (WH), Transparent (CL)
    Colour Marking Field White (WH)
    Fixation Method Pasting / Stick
    Material Type 1232, Polyester, white transparent, self-laminating (1232)
    Mech. material properties Due to its flexibility particularly suitable for identification of cables.
    PART DESCRIPTION TAG32-135TD1-1232-CL/WH
    Pack Cont. 650pcs.
    Package Content packed in reel
    Product Family Helatag 1232
    Product Group Self-laminating labels, thermal transfer
    Self adhesive (Yes/No) Yes
    Short Description Self-laminating labels, thermal transfer 32X135 mm white-transparent, 1 reel = 650pcs.
    Type TAG32-135TD1
    Variant Roller form
    With label space Yes
    Bundle Diameter max (metric) 30.88mm
    Bundle ∅ 14.01-30.88mm
    Bundle ∅ min. 14.01mm
    H printable 39.87mm
    Height (H) 39.87mm
    Height (H2) 134.62mm
    Print Method thermal transfer print
    Thickness of Foil 50
    Weight/Unit 0.000939kg
    Width (W) 31.75mm
    Width of LIner (WL) 1.49"
    Width of Liner (WL) 38.00mm
    Adhesive Acrylic
    Adhesive Operating Temperature -40 °C to +150 °C
    CE Certification No
    CSA Certified No
    Curing Temperature from +2 °C
    ELV compliant (Article 4 - 2) YES
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +150 °C
    ROHS compliant Yes
    Recommended Ribbon Type TT822OUT
    Resistance to Brake cleaner: 720h (at room temperature), Alcohol 94%: 720h (at room temperature), Hydraulic oil: 720h (at room temperature)
    Specifications
    UV-Stabilised Yes
    Country of Origin DE
    Customs Number 39199080
    GTIN-13 / EAN 4031026622644
    Labels per Column 1
    Labels per Row 1pc.
    Packaging 1 - Height (m) 0.032m
    Packaging 1 - Length (m) 0.135m
    Packaging 1 - Qty 650
    Packaging 1 - Type reel
    Packaging 1 - Volume (m³) 0.00058m³
    Packaging 1 - Weight (kg) 0.61kg
    Packaging 1 - Width (m) 0.135m
    Packaging 3 - Height (m) 0.11m
    Packaging 3 - Length (m) 0.144m
    Packaging 3 - Qty 650
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0022m³
    Packaging 3 - Weight (kg) 1.11kg
    Packaging 3 - Width (m) 0.139m
    Packaging 4 - Height (m) 1.244m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 364000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.194m³
    Packaging 4 - Weight (kg) 642.796kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC001530
    ETIM 8.0 Key EC001530
    ETIM 9.0 Key EC001530
    UNSPSC Key 55121612
