22/12/2024

Fixing tie for hole (round), inside serrated, ∅1.5-31.0mm, black, 1000pcs.
Nr. articol 150-15395 | T50SST5-PA66HIRHS-BK |  Detalii

The flexible 'discs' adjusts to take up variations in panel thickness - ensuring a firm fixing at all times.

    • Arrowhead simply locks into place
    • Disc covering hole for reduced ingress of dust, dirt and water
    • Adjustable anchor for differing panel thickness to ensure secure fixing
    • RT versions are releasable and reusable, ideal for removal or later addition of cables
    • T50SST type with small tab for additional protection against axial forces
    • Useful to assist retention on convoluted tubing
    arată mai mult
    Adăugați la lista de urmărire

    Solicitați acum oferta dumneavoastră individuală

     Solicitați oferta
    Downloads
    Application With a diverse range of fixing possibilities this range of fixing ties are ideal for use in many different industries, like: automotive, aerospace, white goods manufacture and panel building.
    Colour Black (BK)
    Fixation Method arrowhead
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T50SST5-PA66HIRHS-BK
    Pack Cont. 1000pcs.
    Package Content packed in pcs.
    Product Family for round holes
    Product Group 1-piece fixing ties with arrowhead, with disc
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50SST5
    Variant Inside Serrated
    Bundle Diameter max (metric) 31.0mm
    Bundle ∅ 1.5-31.0mm
    Bundle ∅ min. 1.5mm
    Disc ∅ 16.2mm
    Length (L) 170.0mm
    Min.Tensile Strength 225N
    Panel Thickness max. 0.7 – 1.5mm
    Thickness (T) 1.2mm
    Weight/Unit 0.0013kg
    Width (W) 4.6mm
    for Hole ∅ (FH) 6.1 - 6.5 mm
    for Panel Thickness min - max 0.7 - 1.5 mm
    for Panel Thickness min - max 0 - 0.1 "
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin FR
    Customs Number 39269097
    GTIN-13 / EAN 4031026119557
    Packaging 1 - Height (m) 0.2m
    Packaging 1 - Length (m) 0.47m
    Packaging 1 - Qty 1000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.05123m³
    Packaging 1 - Weight (kg) 1.44kg
    Packaging 1 - Width (m) 0.545m
    Packaging 3 - Height (m) 0.368m
    Packaging 3 - Length (m) 0.584m
    Packaging 3 - Qty 6000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.083m³
    Packaging 3 - Weight (kg) 9.46kg
    Packaging 3 - Width (m) 0.386m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 72000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 134.52kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
