Connector clip for hole (oval), black, 10000pcs.
Nr. articol 151-00840 | CC-PAEKSFT6.5PT1.7-2.3-PA66HIRHS-BK |  Detalii

    • Connector easily installed by simply pushing into place
    • Connection can be released (non-destructive)
    • Arrowhead locks into place for secure fixing at all times
    Adăugați la lista de urmărire

    Solicitați acum oferta dumneavoastră individuală

     Solicitați oferta
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CC-PAEKSFT6.5PT1.7-2.3-PA66HIRHS-BK
    Pack Cont. 10000pcs.
    Package Content packed in bag
    Product Family With Arrowhead
    Product Group Connector Clips for round holes
    Short Description Connector Clip, high impact modified, heat stabilised, black
    Type CC-PAEKSFT6.5PT1.7-2.3
    Height (H) 13.4mm
    Length (L) 16.0mm
    Weight/Unit 0.00077kg
    Width (W) 16.0mm
    for Hole ∅ (FH) 6.3 - 6.7 mm
    for Panel Thickness min - max 1.7 - 2.3 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin FR
    Customs Number 39269097
    GTIN-13 / EAN 4031026411354
    Packaging 1 - Height (m) 0.184m
    Packaging 1 - Length (m) 0.58m
    Packaging 1 - Qty 10000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.04055m³
    Packaging 1 - Weight (kg) 7.766663kg
    Packaging 1 - Width (m) 0.38m
    Packaging 3 - Height (m) 0.184m
    Packaging 3 - Length (m) 0.58m
    Packaging 3 - Qty 10000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0406m³
    Packaging 3 - Weight (kg) 8.366663kg
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 240000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 221.808kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121702
