Connector clip for connector/for hole (round), black, 500pcs.
Nr. articol 151-01466 | CC1SFT7PT2.3-3.5-PA66HIRHS-BK |  Detalii

    • Connector easily installed by simply pushing into place
    • Connection can be released (non-destructive)
    • Arrowhead locks into place for secure fixing at all times
    Adăugați la lista de urmărire

    Solicitați acum oferta dumneavoastră individuală

     Solicitați oferta
    Downloads
    Colour Black (BK)
    Key product features sealed
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CC1SFT7PT2.3-3.5-PA66HIRHS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family With Arrowhead
    Product Group Connector Clips for round holes
    Type CC1SFT7PT2.3-3.5
    Length (L) 17.0mm
    Panel Thickness max. 2.3 - 3.5mm
    for Hole ∅ (FH) 6.8 - 7.2 mm
    for Panel Thickness min - max 2.3 - 3.5 mm
    Operating Temperature -40 °C to +105 °C
    Country of Origin CN
    GTIN-13 / EAN 4031026541877
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121702
    Afișare toate
