Cable tie inside serrated, 390.0x4.8mm, ∅1.5-110.0mm, black, 1000pcs.
Art.-No. 111-01128 | T50L-PA66HIRHSUV-BK |  Details

Head design guarantees high tensile strength and a low insertion force.

    • Available in a wide range of materials and sizes
    • High tensile strength with very low insertion force
    • Only high quality plastic is used meeting recycling targets
    • Inside serrated cable ties for a strong hold onto bundles
    • Ergonomic bent tail offers quick and simple installation
    • Easy application either manually or with an application tool
    Show more
    Add to watchlist
    Downloads Datasheet e-Learning
    Application T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.
    Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
    Colour Black (BK)
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T50L-PA66HIRHSUV-BK
    Pack Cont. 1000pcs.
    Package Content packed in bag
    Product Group Cable Ties inside serrated
    Releasable Closure (Yes/No) No
    Short Description Cable Tie 390x4.6 mm, high impact modified, heat and UV stabilised, black
    Tie Closure plastic pawl
    Type T50L
    Variant Inside Serrated
    Bundle Diameter max (metric) 110.0mm
    Bundle ∅ 1.5-110.0mm
    Bundle ∅ min. 1.5mm
    Cable Tie Head Length (metric) 7.2mm
    Cable Tie Head Width (metric) 8.1mm
    Length (L) 390.0mm
    Min.Tensile Strength 225N
    Strap Width max. (G) 0.32"
    Thickness (T) 1.4mm
    Weight/Unit 0.0027kg
    Width (W) 4.8mm
    CE Certification Yes
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US) Yes
    UL Type 11
    UL-File Number E64139
    UV-Stabilised Yes
    Country of Origin US
    Customs Number 39269097
    GTIN-13 / EAN 4031026423470
    Packaging 1 - Height (m) 0.03m
    Packaging 1 - Length (m) 0.05334m
    Packaging 1 - Qty 1000
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00007m³
    Packaging 1 - Weight (kg) 2.700001kg
    Packaging 1 - Width (m) 0.04572m
    Packaging 3 - Height (m) 0.2159m
    Packaging 3 - Length (m) 0.606425m
    Packaging 3 - Qty 5000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.052m³
    Packaging 3 - Weight (kg) 14.360005kg
    Packaging 3 - Width (m) 0.396875m
    Packaging 4 - Height (m) 1.224m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 75000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.175m³
    Packaging 4 - Weight (kg) 236.4kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
