08/11/2024

Fixing tie for hole (round), inside serrated, ∅4.0-35.0mm, black, 500pcs.
Art.-No. 156-00058 | T30RFT8-PA66HS-BK |  Details

These fir tree fixings can also be used in threaded, blind holes.

    Package size
    Add to watchlist
    Downloads Datasheet
    Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
    Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP
    Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
    Colour Black (BK)
    Fixation Method Fir Tree
    Foot Part Polyamide 6.6, heat stabilised (PA66HS)
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION T30RFT8-PA66HS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family Fir tree parts FT8
    Product Group 2-piece fixing ties with fir tree, with disc, for round holes
    Tie Closure plastic pawl
    Type T30RFT8
    Variant Inside Serrated
    Bundle Diameter max (metric) 35.0mm
    Bundle ∅ 4.0-35.0mm
    Bundle ∅ min. 4.0mm
    Disc ∅ 16.0mm
    Height (H) 1.1mm
    Height (H2) 11.5mm
    Length (L) 150.0mm
    Length (L2) 12.0mm
    Length (L3) 17.8mm
    Min.Tensile Strength 135N
    Thickness (T) 1.1mm
    Width (W) 3.5mm
    Width (W2) 9.0mm
    Width (W3) 9.0mm
    for Hole ∅ (FH) 7.7 - 8.0 mm
    for Panel Thickness min - max 0.8 - 6 mm
    for Panel Thickness min - max 0 - 0.3 "
    Flammability UL 94 V2
    Operating Temperature -40 °C to +105 °C
    Operating Temperature Foot Part (Metric) -40 °C to +105 °C, (+145 °C, 500 h)
    ROHS compliant Yes
    Specifications
    Country of Origin SG
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
    Show all
    Show all
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...
