Fixing tie for hole (round), outside serrated, ∅1.0-45.0mm, black, 500pcs.
Art.-No. 156-03587
| S50ROSFT8GSD-PP/PA66HIRHS-BK
|
Details
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- The S50ROS features a significantly lower CO₂ footprint compared to cable ties made of standard material, in line with sustainability goals in various industries
- The outside serration design ensures gentle handling of sensitive cables and bundles, reducing the risk of damage during installation and maintenance
- With an anti-slip feature on the inside, the S50ROS prevents undesired lateral movement of cables and bundles, maintaining tidy and organized cable management within vehicles
- Easy to assemble without the need for a tool
- Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
More products in this product group:
| Application | S-Series cable ties made from Polypropylene (PP) are non hydroscopic, offer a higher chemical resistance and reduced CO2 footprint compared to a standard cable tie material. These cable ties are used to bundle and secure cables, pipes and/or hoses. |
| Application Tool | EVO7, EVO7SP, EVO7i, EVO7iSP |
| Colour | Black (BK) |
| Fixation Method | Fir Tree |
| Identification Plate Position | none |
| Material | Polypropylene (PP), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | S50ROSFT8GSD-PP/PA66HIRHS-BK |
| Pack Cont. | 500pcs. |
| Package Content packed in | bag |
| Product Family | Fir tree parts FT8 |
| Product Group | 2-piece fixing ties with fir tree, with disc, for round holes |
| Releasable Closure (Yes/No) | No |
| Short Description | 2-Piece Fixing Tie with Fir Tree and Disc 200x4.9 |
| Tie Closure | plastic pawl |
| Type | S50ROSFT8GSD |
| Variant | Outside Serrated with AntiSlip Engraving |
|
|
| Bundle Diameter max (metric) | 45.0mm |
| Bundle ∅ | 1.0-45.0mm |
| Bundle ∅ min. | 1.0mm |
| Cable Tie Head Height (metric) | 7.5mm |
| Cable Tie Head Length (metric) | 8.3mm |
| Cable Tie Head Width (metric) | 8.95mm |
| Disc ∅ | 16.0mm |
| Height (H) | 1.45mm |
| Height (H2) | 17.2mm |
| Length (L) | 200.00mm |
| Min.Tensile Strength | 185N |
| Panel Thickness max. | 1.5 - 4.0mm |
| Thickness (T) | 1.45mm |
| Weight/Unit | 0.0021kg |
| Width (W) | 4.90mm |
| for Hole ∅ (FH) | M10, 8.0 - 8.5 mm |
| for Panel Thickness min - max | 1.5 - 4 mm |
Download
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026752433 |
| Packaging 1 - Height (m) | 0.1m |
| Packaging 1 - Length (m) | 0.36m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.01152m³ |
| Packaging 1 - Weight (kg) | 1.079135kg |
| Packaging 1 - Width (m) | 0.32m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 3000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 7.29481kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 36000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 108.528kg |
| Packaging 4 - Width (m) | 0.8m |
