Fixing tie with pipe/tube holder, ∅5-30mm, black, 100pcs.
Art.-No. 156-00894 | T30ROC5J-P-PA66HSUV-BK Details

  • Fixed the cable and piping in the tie, the clip portion is freely moved cable installed.
  • The clip portion can be attached to the cable of up to 5mm diameter in one touch.
  • After putting the cable in the clip part, you can adjust the position of the cable by sliding with anti-slip function, the degree of freedom of design is enlarged.
Application Can be used for fixing on cables, piping, and sliding at the same time.
Cable Tie Polyamide 6.6, heat and UV-stabilised (PA66HSUV)
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Key product features lockable, rotatable
Material Polyamide 6.6, heat and UV-stabilised (PA66HSUV)
PART DESCRIPTION T30ROC5J-P-PA66HSUV-BK
Pack Cont. 100pcs.
Package Content packed in bag
Product Family Omega clip tie T30ROC5J_Series
Product Group 2-piece fixing ties with pipe clip
Releasable Closure (Yes/No) No
Type T30ROC5J-P
Attach to Diameter 0.43 "
Attach to Ø 11.0
Bundle Diameter max (metric) 30mm
Bundle ∅ 5-30mm
Bundle ∅ min. 5mm
Length (L) 152.0mm
Min.Tensile Strength 135N
Thickness (T) 1.2mm
Weight/Unit 0.00207kg
Width (W) 3.5mm
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2
Hazardous Goods No
Operating Temperature -40 °C to +110 °C
ROHS compliant Yes
Specifications
UV-Stabilised Yes
Country of Origin JP
Customs Number 39269097
GTIN-13 / EAN 4944387101201
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 0.207001kg
Packaging 3 - Height (m) 0.315m
Packaging 3 - Length (m) 0.505m
Packaging 3 - Qty 2000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0589
Packaging 3 - Weight (kg) 4.67002kg
Packaging 3 - Width (m) 0.37m
Packaging 4 - Height (m) 1.089m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 24000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.045
Packaging 4 - Weight (kg) 77.04kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121717
