Fixing tie with pipe/tube holder, ∅5-30mm, grey, 2000pcs.
Art.-No. 156-00895 | T30ROC5J-P-PA66HS-GY Details

  • Fixed the cable and piping in the tie, the clip portion is freely moved cable installed.
  • The clip portion can be attached to the cable of up to 5mm diameter in one touch.
  • After putting the cable in the clip part, you can adjust the position of the cable by sliding with anti-slip function, the degree of freedom of design is enlarged.
Application Can be used for fixing on cables, piping, and sliding at the same time.
Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
Colour Grey (GY)
Fixation Method Omega Clip
Identification Plate Position none
Key product features lockable, rotatable
Material Polyamide 6.6, heat stabilised (PA66HS)
PART DESCRIPTION T30ROC5J-P-PA66HS-GY
Pack Cont. 2000pcs.
Package Content packed in box
Product Family Omega clip tie T30ROC5J_Series
Product Group 2-piece fixing ties with pipe clip
Type T30ROC5J-P
Attach to Diameter 0.43 "
Attach to Ø 11.0
Bundle Diameter max (metric) 30mm
Bundle ∅ 5-30mm
Bundle ∅ min. 5mm
Length (L) 152.0mm
Min.Tensile Strength 135N
Thickness (T) 1.2mm
Width (W) 3.5mm
Flammability UL 94 V2
Operating Temperature -40 °C to +110 °C
ROHS compliant Yes
Specifications
UV-Stabilised No
Country of Origin JP
GTIN-13 / EAN 4944387101218
Packaging 3 - Weight (kg) 6.26kg
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121717
