22/12/2024

Fixing tie for edge, inside serrated, ∅1.5-45.0mm, black, 4000Set
Art.-No. 156-00261 | T50RATSEC37SET-PA66HS/PA66HIRHS-BK |  Details

T50ROSEC10 fitted onto a plastic panel to hold a Ø 6 mm harness.

    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Content 4000 T50R + 4000 ATSEC37
    Fixation Method Edge Clip
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T50RATSEC37SET-PA66HS/PA66HIRHS-BK
    Pack Cont. 4000Set
    Package Content packed in box
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50RATSEC37SET
    Variant Inside Serrated
    Bundle Diameter max (metric) 45.0mm
    Bundle ∅ 1.5-45.0mm
    Bundle ∅ min. 1.5mm
    Height (H) 1.2mm
    Height (H2) 14.7mm
    Length (L) 200.0mm
    Length (L2) 15.0mm
    Min.Tensile Strength 225N
    Weight/Unit 0.003439kg
    Width (W) 4.6mm
    Width (W2) 16.4mm
    for Panel Thickness min - max 1.5 - 4 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin DE
    Customs Number 39269097
    GTIN-13 / EAN 4031026270012
    Packaging 3 - Height (m) 0.204m
    Packaging 3 - Length (m) 0.591m
    Packaging 3 - Qty 4000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.048m³
    Packaging 3 - Weight (kg) 14.406kg
    Packaging 3 - Width (m) 0.398m
    Packaging 4 - Height (m) 1.164m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 80000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.117m³
    Packaging 4 - Weight (kg) 309.12kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121731
