22/12/2024

Fixing tie for cable bundles, inside serrated, ∅2.0-47.0mm, orange/black, 500pcs.
Art.-No. 156-04062 | T50RCOUPLER-PA66HIRHS/PA66HIRHSUV-OG/BK |  Details

Pre-assembled self-affixing tie with coupler.

    • Pre-assembled 2-piece fixing tie with coupler
    • Cable tie head can be moved after bundling
    • Easy addition of cables after assembly
    • For parallel routing of bundles that can be twisted 90° even after installation
    Add to watchlist
    Downloads Datasheet
    Colour Orange (OG), High Voltage (HV), Black (BK)
    Description The Coupler is the simple way to connect two cable ties for a parallel routing of two bundles. His special design allows the ties 90 degrees of rotation. This is ideal for all applications where the cable, pipe or hose should move flexible in relation to the fixing point. The Coupler can be used with one or two cable ties. This allows easily subsequent installation or replacements of further cables, pipes or hose.
    For Ties T50
    Identification Plate Position none
    Key product features for multiple routing
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T50RCOUPLER-PA66HIRHS/PA66HIRHSUV-OG/BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family T50RCoupler for max. bundle diameter 2 x 47.0 mm
    Product Group 2-piece fixing ties for parallel separation
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50RCOUPLER
    Variant Inside Serrated
    Bundle Diameter max (metric) 47.0mm
    Bundle ∅ 2.0-47.0mm
    Bundle ∅ min. 2.0mm
    Height (H) 8.3mm
    Length (L) 202.0mm
    Min.Tensile Strength 225N
    Strap Width max. (G) 0.18"
    Strap Width max. (G) 4.70mm
    Width (W) 4.6mm
    ∅ max. 1. loop 50.0mm
    ∅ max. 2. loops 50.0mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    Country of Origin FR
    GTIN-13 / EAN 4031026665924
    Packaging 3 - Height (m) 0.200m
    Packaging 3 - Length (m) 0.511m
    Packaging 3 - Qty 1000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0318m³
    Packaging 3 - Weight (kg) 4.1kg
    Packaging 3 - Width (m) 0.311m
    Packaging 4 - Qty 40000
    Packaging 4 - Type pallet
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
