Fixing tie for edge, black, 500pcs.
Art.-No. 156-04131 | T50ROSEC2.5A-REV-PA66HS/PA66HIRHS-BK Details

Application Due to the tie's reduced installation height it is ideal for use wherever space is at a premium.
Colour Black (BK)
Description This EdgeClip is very easy to mount. The holding tab snaps into the drill hole very securely. You will hear and feel the connection being made during mounting. Cable ties from a variety of product series and varying in terms of their dimensions and materials can be used in conjunction with this fixing element.
Fixation Method Edge Clips without metal insert
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION T50ROSEC2.5A-REV-PA66HS/PA66HIRHS-BK
Pack Cont. 500pcs.
Package Content packed in bag
Product Family for drill holes
Product Group 2-piece fixing ties for edges
Type T50ROSEC2.5A-REV
ROHS compliant Yes
Specifications
Country of Origin CN
GTIN-13 / EAN 4031026673912
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
