10/01/2025

Fixing tie for hole (round), ∅2.0-50.0mm, grey, 500pcs.
Art.-No. 157-04136 | T50ROSFTM6SO12.5B-PA46-GY |  Details

The fir tree mount cable tie is an all-in-one bundling and fastening solution that reduces costs and assembly time.

    • Bundling and fixing solution
    • Ideal combination of materials and design
    • Different positions of the fixing anchor are available to fit installation space
    Add to watchlist
    Downloads Datasheet
    Colour Grey (GY)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 4.6 (PA46)
    PART DESCRIPTION T50ROSFTM6SO12.5B-PA46-GY
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family With offset 12.5 and 25.0 mm
    Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for round holes
    Releasable Closure (Yes/No) No
    Short Description 1-Piece Fixing Ties with Fir Tree and Disc, with Stand-off, for Round Holes
    Type T50ROSFTM6SO12.5B
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ 2.0-50.0mm
    Bundle ∅ min. 2.0mm
    Length (L) 215.5mm
    Length (L2) 12.5mm
    Min.Tensile Strength 225N
    Offset Length 12.5mm
    Panel Thickness max. 0.5 - 6.65mm
    Width (W) 4.7mm
    for Hole ∅ (FH) M6
    for Panel Thickness min - max 0.5 - 6.7 mm
    for Panel Thickness min - max 0 - 0.3 "
    CE Certification No
    CSA Certified No
    Flammability UL 94 V2
    Halogen-free Yes
    ROHS compliant Yes
    Specifications
    Country of Origin US
    GTIN-13 / EAN 4031026734361
    Packaging 3 - Height (m) 0.37465m
    Packaging 3 - Length (m) 0.59055m
    Packaging 3 - Qty 500
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0646m³
    Packaging 3 - Weight (kg) 7.03kg
    Packaging 3 - Width (m) 0.2921m
    Packaging 4 - Qty 72000
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
