Fixing tie with pipe/tube holder, outside serrated, ∅2.0-35.0mm, black, 500pcs.
Art.-No. 156-03036 | T50SOSASVC6.5-PA66HIRHS-BK Details

  • Simply clip on a wire or hose
  • Fixing clip offers full 360° rotation
  • Routed cable can move in any direction in relation to the fixing point
  • Ideally used in the Automotive Industry
Application These outside serrated fixing ties provide the opportunity to attach a wire or hose to an existing harness. Offering a full 360 degrees rotation, the wire/hose can be oriented in any direction in relation to the main harness.
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION T50SOSASVC6.5-PA66HIRHS-BK
Pack Cont. 500pcs.
Package Content packed in bag
Product Group 2-piece fixing ties with pipe clip
Short Description 2-piece fixing ties with pipe clip, twistable 360°, heat stabilised / high impact modified, black, outside serrated, anti-slip engraving
Tie Closure plastic pawl
Type T50SOSASVC6.5
Variant Outside Serrated
Attach to Ø 6.5 - 8.0
Bundle Diameter max (metric) 35.0mm
Bundle ∅ 2.0-35.0mm
Bundle ∅ min. 2.0mm
Length (L) 155.0mm
Min.Tensile Strength 200N
Thickness (T) 1.3mm
Weight/Unit 0.001747kg
Width (W) 4.6mm
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
ROHS compliant Yes
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026645636
Packaging 1 - Height (m) 0.05m
Packaging 1 - Length (m) 0.45m
Packaging 1 - Qty 500
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00889
Packaging 1 - Weight (kg) 0.902635kg
Packaging 1 - Width (m) 0.395m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 6000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Width (m) 0.386m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 72000
Packaging 4 - Type pallet
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121702
