02/11/2024

Fixing tie with pipe/tube holder, ∅2.0-35.0mm, black, 250pcs.
Art.-No. 156-00798 | T50SVCOC25-31-PA66HS/PA66HIRHS-BK Details

Application These inside serrated fixing ties provide the opportunity to attach a wire or hose to an existing harness. Offering a full 360 degrees rotation, the wire/hose can be oriented in any direction in relation to the main harness.
Application Tool ProCut 9 no battery, MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP, EVO9, EVO9SP, EVO9i, EVO9iSP
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Key product features rotatable
Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION T50SVCOC25-31-PA66HS/PA66HIRHS-BK
Pack Cont. 250pcs.
Package Content packed in bag
Product Group 2-Piece Fixing Ties with Pipe Clip, twistable 360°
Tie Closure plastic pawl
Type T50SVCOC25-31
Attach to Diameter 0.98 - 1.22 "
Attach to Ø 25.0 - 31.0
Bundle Diameter max (metric) 35.0mm
Bundle ∅ 2.0-35.0mm
Bundle ∅ min. 2.0mm
Length (L) 155.0mm
Min.Tensile Strength 222N
Thickness (T) 1.35mm
Width (W) 4.7mm
for Hole ∅ (FH) 25.0 - 31.0 mm
Flammability UL 94 HB
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
Country of Origin CN
GTIN-13 / EAN 4031026430539
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121702
