Cable clip for hole (round)/for stud, Dmin=16.5mm, Dmax=17.5mm, black, 350pcs.
Art.-No. 151-03791 | HDC17x3-PA66GF15/TPE-BK |  Details

    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Key product features vibration absorbing, sealed, for multiple routing
    Material Polyamide 6.6, glass-fibre reinforced (PA66GF15), Thermoplastic Elastomer (TPE)
    PART DESCRIPTION HDC17x3-PA66GF15/TPE-BK
    Pack Cont. 350pcs.
    Package Content packed in carton
    Product Family for multiparallel routing
    Product Group Fixing elements for tubes and harnesses
    Type HDC17x3
    Bundle Diameter max (metric) 17.5mm
    Bundle ∅ 16.5-17.5mm
    Bundle ∅ min. 16.5mm
    Fixing Hole Centres (F) 1.73"
    Fixing Hole Centres (F) 44.0mm
    Height (H) 33.2mm
    Length (L) 126.3mm
    Length (L2) 44.0mm
    Weight/Unit 0.03198kg
    Width (W) 26.0mm
    ∅ max. 1. loop 17.5mm
    ∅ max. 2. loops 17.5mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +125 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    Country of Origin US
    Customs Number 39269097
    GTIN-13 / EAN 4031026691138
    Packaging 1 - Qty 350
    Packaging 1 - Type bag
    Packaging 1 - Weight (kg) 11.193kg
    Packaging 3 - Height (m) 0.219075m
    Packaging 3 - Length (m) 0.606425m
    Packaging 3 - Qty 350
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0529m³
    Packaging 3 - Weight (kg) 11.963kg
    Packaging 3 - Width (m) 0.3984625m
    Packaging 4 - Height (m) 1.239m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 5250
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.189m³
    Packaging 4 - Weight (kg) 200.445kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
