Cable clip for hole (round)/for stud, ⌀M8 x 1.25 Threaded, Dmin=21.5mm, Dmax=22.5mm
Art.-No. 151-03994 | HDC22x3-PA66GF15/TPE-BK |  Details

Double and triple high voltage clips.

    Add to watchlist
    Downloads
    Colour Black (BK)
    Key product features vibration absorbing, sealed, for multiple routing
    Material Polyamide 6.6, glass-fibre reinforced (PA66GF15), Thermoplastic Elastomer (TPE)
    PART DESCRIPTION HDC22x3-PA66GF15/TPE-BK
    Pack Cont. 300pcs.
    Package Content packed in carton
    Product Family for multiparallel routing
    Product Group Fixing elements for tubes and harnesses
    Type HDC22x3
    ⌀ max. 1. loop 22.5mm
    ⌀ max. 2. loops 22.5mm
    Bundle ⌀ 21.5-22.5mm
    Bundle ⌀ min. 21.5mm
    Bundle Diameter max (metric) 22.5mm
    Height (H) 38.0mm
    Height (H2) 19.0mm
    Length (L) 132.5mm
    Width (W) 26.0mm
    for Hole ⌀ (FH) M8 x 1.25 Threaded
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026713991
    Packaging 1 - Qty 300
    Packaging 1 - Type bag
    Packaging 3 - Height (m) 0.20955m
    Packaging 3 - Length (m) 0.606425m
    Packaging 3 - Qty 300
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0504m³
    Packaging 3 - Width (m) 0.396875m
    Packaging 4 - Qty 9000
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
