Cable grommet, ∅18.0 mm, black, 500pcs.
Art.-No. 633-03050 | HV1305-PVC-FR-BK |  Details

Edge Protection Grommet - HV1305.

    • Protects cables from sharp edges
    • Provides additional strain relief
    • Flexible and easy to apply
    • High resistance to chemicals and environmental influences
    Add to watchlist
    Downloads CAD-Download Datasheet
    Application Edge protection grommets are used wherever cable and wires are routed through apertures. HellermannTyton grommets offer excellent mechanical protection.
    Cable ∅ max 15.0mm
    Cable ∅ min 14.0mm
    Colour Black (BK)
    Material Polyvinylchloride, flame retardant (PVC-FR)
    PART DESCRIPTION HV1305-PVC-FR-BK
    Pack Cont. 500pcs.
    Package Content packed in pcs.
    Product Family Edge protection grommets
    Product Group For apertures
    Short Description Edge protection grommets black, outside diameter: 24.0mm, inside diameter: 14.0mm, height: 7.0mm
    Type HV1305
    Variant Round
    Diameter (D) 14.0mm
    Height (H) 7.0mm
    Height (H2) 3.0mm
    Outside Ø (OD) 24.0mm
    Shore Hardness A 55±5
    Weight/Unit 0.0018kg
    for Hole ∅ (FH) 18.0 mm
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V0
    Halogen-free No
    Hazardous Goods No
    Nato number 5325-12-152-2352
    Operating Temperature -30 °C to +60 °C
    ROHS compliant Yes
    Specifications
    Country of Origin DE
    Customs Number 39269097
    GTIN-13 / EAN 4031026186474
    Packaging 1 - Height (m) 0.06m
    Packaging 1 - Length (m) 0.35m
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.0084m³
    Packaging 1 - Weight (kg) 0.900001kg
    Packaging 1 - Width (m) 0.4m
    ETIM 7.0 Key EC000879
    ETIM 8.0 Key EC000879
    ETIM 9.0 Key EC000879
    UNSPSC Key 24141510
