Cable tie mount for screw fixation, Wmax=5.0mm, ∅4.3 mm, M4 Screw, beige, 100pcs.
Številka proizvoda 151-00757
| CTAM1-PEEK-BGE
|
Podrobnosti
- Suitable for applications with minimal space
- Mounted before cable installation and in line with cable
- CTAM has 4-way entry design for use in line or at 90° angle to cable run
- For high temperature application from -55° C up to +240° C
- High chemical resistance
- Radiation resistance
Zahtevajte svojo individualno ponudbo zdaj
Zahtevajte ponudbo
More products in this product group:
| Application | The CTAM-series offers particular benefits due to its small size and can be used even in compact spaces. CTAM mounts manufactured from PEEK material offer even more benefits. They have been specially designed for the use in hazardous environment. Its suitability for high temperature applications makes it useful for the drilling industry, railway, offshore or automotive industry. The excellent chemical and radium ray resistance is predestined for applications in medical engineering, chemical industry and power stations. Because of this combination of different properties PEEK mounts can replace metal solutions. |
| Colour | Beige (BGE) |
| Fixation Method | Screw Mount |
| For Ties | T18 - T50 |
| Material | Polyetheretherketone (PEEK) |
| Mounting Screw Type | M4 Screw |
| PART DESCRIPTION | CTAM1-PEEK-BGE |
| Pack Cont. | 100pcs. |
| Package Content packed in | bag |
| Product Family | CTAM-PEEK for high temperature applications up to +240 °C |
| Product Group | Screw Fixing Mounts |
| Short Description | Screw Fixing Mount beige 20.5x10.2 mm for high temperature applications up to +240 °C |
| Type | CTAM1 |
Prenos
|
|
|
| Country of Origin | JP |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4944387956252 |
| Packaging 1 - Height (m) | 0.02m |
| Packaging 1 - Length (m) | 0.17m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00034m³ |
| Packaging 1 - Weight (kg) | 0.050001kg |
| Packaging 1 - Width (m) | 0.1m |
| Packaging 3 - Height (m) | 0.18m |
| Packaging 3 - Length (m) | 0.45m |
| Packaging 3 - Qty | 5000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0251m³ |
| Packaging 3 - Weight (kg) | 2.71005kg |
| Packaging 3 - Width (m) | 0.31m |
| Packaging 4 - Height (m) | 1.224m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 120000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.175m³ |
| Packaging 4 - Weight (kg) | 86.04kg |
| Packaging 4 - Width (m) | 0.8m |
