Fixing tie for hole (round), outside serrated, ∅2.0-45.0mm, black, 100pcs.
Številka proizvoda 156-00360
| T50ROSFT8-PA66HS-BK
|
Podrobnosti
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- Easy to assemble without the need for a tool
- Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
![](https://www.hellermanntyton.com/shared/speclogos/99595_All_Languages.jpg)
Zahtevajte svojo individualno ponudbo zdaj
Zahtevajte ponudbo
More products in this product group:
Application | Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines. |
Colour | Black (BK) |
Fixation Method | Fir Tree |
Identification Plate Position | none |
Material | Polyamide 6.6, heat stabilised (PA66HS) |
Mounting Screw Type | Plated through hole |
PART DESCRIPTION | T50ROSFT8-PA66HS-BK |
Pack Cont. | 100pcs. |
Package Content packed in | bag |
Product Family | Fir tree parts FT8 |
Product Group | 2-piece fixing ties with fir tree, with disc, for round holes |
Releasable Closure (Yes/No) | No |
Tie Closure | plastic pawl |
Type | T50ROSFT8 |
Variant | Outside Serrated |
Bundle Diameter max (metric) | 45.0mm |
Bundle ∅ | 2.0-45.0mm |
Bundle ∅ min. | 2.0mm |
Disc ∅ | 16,0mm |
Height (H2) | 17.8mm |
Hole Depth | 11.5mm |
Length (L) | 200mm |
Length (L2) | 17.4mm |
Min.Tensile Strength | 225N |
Panel Thickness max. | 0.8 - 6.0mm |
Thickness (T) | 1.3mm |
Weight/Unit | 0.0021kg |
Width (W) | 4.6mm |
for Hole ∅ (FH) | 7.7 - 8.0 mm |
for Panel Thickness min - max | 0.8 - 6 mm |
|
|
Country of Origin | GB |
Customs Number | 39269097 |
GTIN-13 / EAN | 4944387951295 |
Packaging 1 - Qty | 100 |
Packaging 1 - Type | bag |
Packaging 1 - Weight (kg) | 0.210001kg |
Packaging 3 - Height (m) | 0.405m |
Packaging 3 - Length (m) | 0.454m |
Packaging 3 - Qty | 3000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.0605m³ |
Packaging 3 - Weight (kg) | 7.13003kg |
Packaging 3 - Width (m) | 0.329m |
Packaging 4 - Height (m) | 0.954m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 30000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 0.916m³ |
Packaging 4 - Weight (kg) | 92.3kg |
Packaging 4 - Width (m) | 0.8m |
