Fixing tie for hole (round), inside serrated, ⌀1.5-31.0mm, natural, 100pcs.
Številka proizvoda 126-00031 | T50SST5-PA46-NA |  Podrobnosti

The flexible 'discs' adjusts to take up variations in panel thickness - ensuring a firm fixing at all times.

    • Arrowhead simply locks into place
    • Disc covering hole for reduced ingress of dust, dirt and water
    • Adjustable anchor for differing panel thickness to ensure secure fixing
    • RT versions are releasable and reusable, ideal for removal or later addition of cables
    • T50SST type with small tab for additional protection against axial forces
    • Useful to assist retention on convoluted tubing
    prikaži več izdelkov
    Ne pozabite

    Zahtevajte svojo individualno ponudbo zdaj

     Zahtevajte ponudbo
    Downloads
    Application With a diverse range of fixing possibilities this range of fixing ties are ideal for use in many different industries, like automotive, aerospace, white goods manufacture and panel building.
    Colour Natural (NA)
    Fixation Method arrowhead
    Identification Plate Position none
    Material Polyamide 4.6 (PA46)
    PART DESCRIPTION T50SST5-PA46-NA
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family for round holes
    Product Group 1-piece fixing ties with arrowhead, with disc
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50SST5
    Variant Inside Serrated
    Bundle ⌀ 1.5-31.0mm
    Bundle ⌀ min. 1.5mm
    Bundle Diameter max (metric) 31.0mm
    Disc ⌀ 16.2mm
    Length (L) 170.0mm
    Min.Tensile Strength 225N
    Thickness (T) 1.2mm
    Width (W) 4.6mm
    for Hole ⌀ (FH) 6.1 - 6.5 mm
    for Panel Thickness min - max 0.7 - 1.5 mm
    Flammability UL 94 V2
    Halogen-free Yes
    Limited Fire Hazard Yes
    Operating Temperature -40 °C to +150 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    GTIN-13 / EAN 4031026710617
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
