Accessory for HWBASE, HWPA-V08, Helawrap, black, 50pcs. (HWCLIP08)
Številka proizvoda 161-64002 | HWCLIP08-PA66HIRHS-BK |  Podrobnosti

HelaWrap - HWClip08.

    • Mounts and routes Helawrap cable cover flexibly and efficiently
    • Fit snugly around the cable cover and holds it tight
    • Each clip can be joined to mounting plate or other clips of any size
    • Each clip rotates freely
    • Easily released and re-used
    prikaži več izdelkov
    Ne pozabite

    Zahtevajte svojo individualno ponudbo zdaj

     Zahtevajte ponudbo
    Downloads
    Application To complete the Helawrap cable management system various Helawrap Clips in compatible sizes are available. The mounting clips can be combined and adjusted individually. Attached to a mounting base the assembly can be screw mounted or directly sticked to the surface.
    Application Method Place cables in applicator, then zip through cover sleeve.
    Colour Black (BK)
    Fixation Method Plug-in mounting
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION HWCLIP08-PA66HIRHS-BK
    Pack Cont. 50pcs.
    Package Content packed in bag
    Product Family HWClips
    Product Group Accessories for Helawrap Cable Cover
    Short Description Fixing clip PA66HIRHS nominal ∅ 8mm black
    Type HWCLIP08
    Diameter (D) 9mm
    Nominal ∅ 0.31"
    Nominal ∅ 8.0mm
    Weight/Unit 0.001118kg
    ∅ D 0.375"
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Melting Point +284 °F (+140 °C)
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin DE
    Customs Number 39269097
    GTIN-13 / EAN 4031026268552
    Packaging 1 - Height (m) 0.025m
    Packaging 1 - Length (m) 0.275m
    Packaging 1 - Qty 50
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00086m³
    Packaging 1 - Weight (kg) 0.061426kg
    Packaging 1 - Width (m) 0.125m
    Packaging 3 - Height (m) 0.184m
    Packaging 3 - Length (m) 0.58m
    Packaging 3 - Qty 4000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0406m³
    Packaging 3 - Weight (kg) 4.2308kg
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 1.249m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 96000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.199m³
    Packaging 4 - Weight (kg) 122.76kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000368
    ETIM 8.0 Key EC000368
    ETIM 9.0 Key EC000368
    UNSPSC Key 39131604
