Cable tie inside serrated for multiple routing, 210x4.7mm, ∅1.6-38.0mm, black, 100pcs.
Art.-No. 117-05050 | T50RDH-PA66HS-BK |  Details

DH-Series cable ties for parallel routing.

    • Possibility to separate bundles with only one cable tie
    • Cable tie with two heads creating an inside and outside serrated loop
    • Available in a wide range of materials
    • Bundles can be of different diameter
    • Maximum bundle diameter is a maximum combined bundle
    • Easy application either manually or with a processing tool
    Show more
    Package size
    Add to watchlist
    Downloads Datasheet e-Learning
    Application Double loop head ties are ideal for separation of two cable runs without the need for additional cable ties. Additionally these ties are widely used within the packaging industry. The first loop closes and secures the bag whilst the second loop can be made into a carrying handle (subject to weight).
    Colour Black (BK)
    Identification Plate Position none
    Key product features for multiple routing
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION T50RDH-PA66HS-BK
    Pack Cont. 100pcs.
    Package Content packed in pcs.
    Product Family DH-Series
    Product Group Cable ties for parallel routing
    Releasable Closure (Yes/No) No
    Short Description Two Head Cable Tie 210x4.7 mm PA66HS black
    Tie Closure plastic pawl
    Type T50RDH
    Variant Inside Serrated
    Bundle Diameter max (metric) 38.0mm
    Bundle ∅ 1.6-38.0mm
    Bundle ∅ min. 1.6mm
    Length (L) 210mm
    Min. Tensile Strength 2nd loop 180N
    Min.Tensile Strength 225N
    Thickness (T) 1.4mm
    Weight/Unit 0.00165kg
    Width (W) 4.7mm
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C, (+145 °C, 500 h)
    ROHS compliant Yes
    Specifications
    Specifications csa-C22.2 no. 62275
    UL OCD link Link
    UL Recognized (US and Canada) Yes
    UL-File Number E64963
    Country of Origin GB
    Customs Number 39269097
    GTIN-13 / EAN 5022660324314
    Packaging 1 - Height (m) 0.025m
    Packaging 1 - Length (m) 0.325m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00122m³
    Packaging 1 - Weight (kg) 0.165kg
    Packaging 1 - Width (m) 0.15m
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Qty 6000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Weight (kg) 10.702kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.164m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 120000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.117m³
    Packaging 4 - Weight (kg) 235.04kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
