07/11/2024

Fixing tie for hole (round), black, 500pcs.
Art.-No. 156-00785 | LR55SFT8-PA66HS-BK |  Details

    Add to watchlist
    Downloads Datasheet
    Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
    Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
    Colour Black (BK)
    Fixation Method Fir Tree
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION LR55SFT8-PA66HS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family Fir tree parts FT8
    Product Group 2-piece fixing ties with fir tree, with disc, for round holes
    Tie Closure plastic pawl
    Type LR55SFT8
    Cable Tie Head Height (metric) 4.1mm
    Cable Tie Head Length (metric) 7.5mm
    Cable Tie Head Width (metric) 7.2mm
    Height (H) 1.2mm
    Height (H2) 17.8mm
    Length (L) 145mm
    Width (W) 4.8mm
    Width (W2) 16mm
    for Panel Thickness min - max 0.8 - 6 mm
    ROHS compliant Yes
    Specifications
    Country of Origin SG
    GTIN-13 / EAN 4031026428345
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
