22/12/2024

Fixing tie for hole (round), ∅1.0-35.0mm, black, 1500pcs.
Art.-No. 126-00397 | T30ROSASVDFT4.7LE-PA66HIRHS-BK |  Details

Fixing tie with vibration damping part and antislip engraving.

    • Bundling and fixing solution
    • Ideal combination of materials and design
    • Different positions of the fixing anchor are available to fit installation space
    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T30ROSASVDFT4.7LE-PA66HIRHS-BK
    Pack Cont. 1500pcs.
    Package Content packed in bag
    Product Family vibration damped
    Product Group 1-Piece fixing ties with fir tree, with wings, for round holes
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T30ROSASVDFT4.7LE
    Variant Outside Serrated with AntiSlip Engraving
    Bundle Diameter max (metric) 35.0mm
    Bundle ∅ 1.0-35.0mm
    Bundle ∅ min. 1.0mm
    Length (L) 174.0mm
    Length (L2) 19.4mm
    Length (L3) 12.7mm
    Min.Tensile Strength 200N
    Offset Length 19.4mm
    Thickness (T) 1.2mm
    Weight/Unit 0.001266kg
    Width (W) 3.45mm
    for Hole ∅ (FH) 4.5 - 5.0 mm
    for Panel Thickness min - max 0.7 - 8 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin PL
    Customs Number 39269097
    GTIN-13 / EAN 4031026647456
    Packaging 1 - Qty 1500
    Packaging 1 - Type bag
    Packaging 1 - Weight (kg) 1.942597kg
    Packaging 3 - Height (m) 0.368m
    Packaging 3 - Length (m) 0.584m
    Packaging 3 - Qty 6000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.083m³
    Packaging 3 - Weight (kg) 8.590388kg
    Packaging 3 - Width (m) 0.386m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 72000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 124.104kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
