Bundling clip for hole (oval), L=58.0mm, natural, 3000pcs.
Številka proizvoda 151-01888
| BCFTOVALXL-PA66HIRHS-NA
|
Podrobnosti
![](https://www.hellermanntyton.com/shared/speclogos/99593_All_Languages.jpg)
![](https://www.hellermanntyton.com/shared/speclogos/99595_All_Languages.jpg)
Zahtevajte svojo individualno ponudbo zdaj
Zahtevajte ponudbo
More products in this product group:
Colour | Natural (NA) |
Fixation Method | Fir Tree for oval holes |
Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
PART DESCRIPTION | BCFTOVALXL-PA66HIRHS-NA |
Pack Cont. | 3000pcs. |
Package Content packed in | carton |
Product Family | Oval holes |
Product Group | Bundling Clips with Fir Tree |
Type | BCFTOVALXL |
Bundling Bar Length | 2.28" |
Bundling Bar Length | 58.0mm |
Fixing Hole Shape | Oval |
Height (H) | 24.58mm |
Height (H2) | 21.03mm |
Length (L) | 13.4mm |
Panel Thickness max. | 0.6 - 11.0mm |
Weight/Unit | 0.00242kg |
Width (W) | 9.6mm |
for Hole ∅ (FH) | 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm |
for Panel Thickness min - max | 0.6 - 11 mm |
CE Certification | No |
CSA Certified | No |
ELV compliant (Article 4 - 2) | YES |
Flammability | UL 94 HB |
Halogen-free | Yes |
Hazardous Goods | No |
Operating Temperature | -40 °C to +110 °C |
ROHS compliant | Yes |
Specifications |
![]() ![]() |
UL Listed (US and Canada) | No |
UL Listed (US and Canada) | No |
UL Recognized (US and Canada) | No |
UL Recognized (US and Canada) | No |
UV-Stabilised | No |
Country of Origin | US |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026577463 |
Packaging 1 - Qty | 3000 |
Packaging 1 - Type | bag |
Packaging 1 - Weight (kg) | 7.260001kg |
Packaging 3 - Height (m) | 0.37465m |
Packaging 3 - Length (m) | 0.59055m |
Packaging 3 - Qty | 3000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.0646m³ |
Packaging 3 - Weight (kg) | 7.760001kg |
Packaging 3 - Width (m) | 0.2921m |
Packaging 4 - Height (m) | 1.212m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 36000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.164m³ |
Packaging 4 - Weight (kg) | 114.12kg |
Packaging 4 - Width (m) | 0.8m |
