Fixing tie for hole (round), ∅1.0-35.0mm, brown, 500pcs.
Art.-No. 157-00478 | T50SOSFT8-E2-PA46-BN Details

  • Cable tie head always situated in defined position
  • Easy to assemble without the need for a tool
  • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
  • Fir tree foot part can be used for a variety of panel thicknesses
  • Suitable for use within threaded holes
Show more
Application Primarily designed for fixing cable harnesses in the automotive industry, their simplicity and ease of use has resulted in these parts being used in other industries, for example aviation, switch gear manufacturer, white goods manufacturer.
Colour Brown (BN)
Fixation Method Fir tree for round holes
Identification Plate Position none
Key product features products for automatic tools
Material Polyamide 4.6 (PA46)
PART DESCRIPTION T50SOSFT8-E2-PA46-BN
Pack Cont. 500pcs.
Package Content packed in bag
Product Family Fir tree parts FT8
Product Group 1-piece fixing ties with fir tree, with disc, for round holes
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50SOSFT8-E2
Bundle Diameter max (metric) 35.0mm
Bundle ∅ 1.0-35.0mm
Bundle ∅ min. 1.0mm
Disc ∅ 16.0mm
Fixing Hole Shape Circular
Length (L) 165.1mm
Min.Tensile Strength 225N
Panel Thickness max. 0.6 - 6.5mm
Width (W) 4.6mm
for Hole ∅ (FH) 7.6 - 8.4 mm
for Panel Thickness min - max 0.6 - 6.5 mm
for Panel Thickness min - max 0 - 0.3 "
CE Certification No
CSA Certified No
Operating Temperature -40 °C to +130 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised No
Country of Origin US
GTIN-13 / EAN 4031026631271
Packaging 3 - Height (m) 0.2159m
Packaging 3 - Length (m) 0.606425m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.052
Packaging 3 - Width (m) 0.396875m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
