24/11/2024

Label, transparent, thermal transfer print, 7.92x15.87mm, 1000pcs.
Art.-No. 596-00029 | TAGPP1T6-822C-CL |  Details

    • Very clear and detailed image for use with graphics, single or sequential characters and especially barcodes
    • Smear-resistant, ultraviolet-resistant and chemical-resistant marking
    Add to watchlist
    Downloads
    Application The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users. The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro.
    Colour Transparent (CL)
    Key product features weather resistant, chemical resistance
    Material Type 822C, Clear Polyester (822C)
    PART DESCRIPTION TAGPP1T6-822C-CL
    Pack Cont. 1000pcs.
    Package Content packed in reel
    Product Family Thermal Transfer Labels
    Product Group Adhesive Labels
    Type TAGPP1T6
    H printable 7.92mm
    HR 15.9mm
    HR 0.63"
    Height (H) 7.92mm
    Print Method thermal transfer print
    Thickness (T) 64.0µm
    VR 19.05mm
    VR 0.75"
    Width (W) 15.87mm
    Width of LIner (WL) 3.80"
    Width of Liner (WL) 96.52mm
    Adhesive Acrylic
    Adhesive Operating Temperature -40 °C to +90 °C, (+160 °C, for 200 h)
    CE Certification No
    CSA Certified No
    Curing Temperature +10 °C
    Halogen-free No
    Operating Temperature -40 °C to +150 °C
    ROHS compliant Yes
    Specifications
    Specifications UL-Recognized
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    GTIN-13 / EAN 4031026727189
    Labels per Column 1
    Labels per Row 6
    Packaging 1 - Weight (kg) 0.68kg
    ETIM 7.0 Key EC001288
    ETIM 8.0 Key EC001288
    ETIM 9.0 Key EC001288
    UNSPSC Key 55121612
