12/11/2024

Label, white, thermal transfer print, 6.35x22.86mm, 10000pcs.
Art.-No. 596-16822 | TAG16T3-822-WH Details

  • Very clear and detailed image for use with graphics, single or sequential characters and especially barcodes
  • Smear-resistant, ultraviolet-resistant and chemical-resistant marking
Application The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users. The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro.
Colour White (WH)
Key product features weather resistant, chemical resistance
Material Type 822, Polyester (822)
PART DESCRIPTION TAG16T3-822-WH
Pack Cont. 10000pcs.
Package Content packed in reel
Product Family Thermal Transfer Labels
Product Group Adhesive Labels
Type TAG16T3
H printable 6.35mm
HR 22.9mm
HR 0.90"
Height (H) 6.35mm
Print Method thermal transfer print
Thickness (T) 64.0µm
VR 8.89mm
VR 0.35"
Width (W) 22.86mm
Width of LIner (WL) 3.35"
Width of Liner (WL) 85.09mm
Adhesive Acrylic
Adhesive Operating Temperature -40 °C to +150 °C
CE Certification No
CSA Certified No
Curing Temperature +10 °C
Halogen-free Yes
Operating Temperature -40 °C to +150 °C
ROHS compliant Yes
Specifications
Specifications UL-Recognized
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL OCD link Link Link
UL Recognized (US and Canada) Yes
UL Recognized (US and Canada) Yes
UL-File Number MH18396
UV-Stabilised No
Country of Origin US
GTIN-13 / EAN 4031026175690
Labels per Column 1
Labels per Row 3
Packaging 1 - Weight (kg) 0.521kg
Packaging 3 - Qty 10000
ETIM 7.0 Key EC001288
ETIM 8.0 Key EC001288
ETIM 9.0 Key EC001288
UNSPSC Key 55121612
