25/12/2024

Cable tie mount with pipe/tube holder, ∅8.2 mm, green, 600pcs.
Art.-Nr. 151-03254 | HDCM2B-PA66GF15-GN |  Details

Separates and secures bundles or convoluted tubing to prevent abrasion.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Green (GN)
    Key product features for multiple routing, releasable
    Material Polyamide 6.6, glass-fibre reinforced (PA66GF15)
    PART DESCRIPTION HDCM2B-PA66GF15-GN
    Pack Cont. 600pcs.
    Package Content packed in bag
    Type HDCM2B
    Variant Separators
    Bundle Diameter max (metric) 17.20mm
    Bundle ∅ 17.20-17.20mm
    Bundle ∅ min. 17.20mm
    Height (H) 34mm
    Length (L) 69.1mm
    Width (W) 28.48mm
    for Hole ∅ (FH) 8.2 mm
    ∅ max. 1. loop 17.20mm
    ∅ max. 2. loops 17.20mm
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +125 °C
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026646565
    Packaging 1 - Qty 600
    Packaging 1 - Type box
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
    Self-Adhesive cable tie mounts Self-Adhesive cable tie mounts

    Self-Adhesive cable tie mounts

    HellermannTyton self-adhesive cable tie mounts are perfectly suited for cable fastening on round and angled surfaces. To save time, reduce part diversity and weight.
