Cable tie mount with pipe/tube holder, ∅8.2 mm, blue, 600pcs.
Art.-Nr. 151-03255 | HDCM2C-PA66GF15-BU |  Details

Separates and secures bundles or convoluted tubing to prevent abrasion.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Blue (BU)
    Key product features for multiple routing, releasable
    Material Polyamide 6.6, glass-fibre reinforced (PA66GF15)
    PART DESCRIPTION HDCM2C-PA66GF15-BU
    Pack Cont. 600pcs.
    Package Content packed in bag
    Type HDCM2C
    Variant Separators
    Height (H) 34mm
    Length (L) 69.1mm
    Width (W) 28.48mm
    for Hole ∅ (FH) 8.2 mm
    ∅ max. 1. loop 23.7mm
    ∅ max. 2. loops 17.20mm
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +125 °C
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026646572
    Packaging 1 - Qty 600
    Packaging 1 - Type box
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
    Self-Adhesive cable tie mounts Self-Adhesive cable tie mounts

    Self-Adhesive cable tie mounts

    HellermannTyton self-adhesive cable tie mounts are perfectly suited for cable fastening on round and angled surfaces. To save time, reduce part diversity and weight.
