23/12/2024

Cable tie mount for screw fixation, ∅6.7 mm, #1/4" (M6) Screw, black, 500pcs.
Art.-Nr. 151-03101 | LPM25-PA666V0-BK |  Details

Low profile design allows mount to be placed in areas where space is limited.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Fixation Method Screw Mounting and Rivet
    For Ties T50 - T250
    Key product features vibration absorbing
    Material Polyamide 6.6/6, V0 (PA666V0)
    Mounting Screw Type #1/4" (M6) Screw
    PART DESCRIPTION LPM25-PA666V0-BK
    Pack Cont. 500pcs.
    Package Content packed in carton
    Type LPM25
    Height (H) 16.7mm
    Length (L) 45.1mm
    Width (W) 24.9mm
    for Hole ∅ (FH) 6.7 mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 V0
    Halogen-free Yes
    Limited Fire Hazard Yes
    Operating Temperature -40 °C to +120 °C
    ROHS compliant Yes
    Specifications
    Specifications ASTM 1354, ASTM E 162, ASTM E 662, NFPA130: 2017
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    GTIN-13 / EAN 4031026633725
    Packaging 1 - Weight (kg) 3.138859kg
    Packaging 3 - Height (m) 0.142875m
    Packaging 3 - Length (m) 0.5159375m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0229m³
    Packaging 3 - Width (m) 0.31115m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
