Cable tie mount for adhesive use, Wmax=4.0mm, ∅2.2 mm, natural, 100pcs.
Art.-Nr. 151-11319
| TY3G1S-PA66-NA
|
Details
- 2-way mounting base for safe guiding of cables and conduits
- Suitable for applications with minimal space
- Mounted before cable installation
![](https://www.hellermanntyton.com/shared/speclogos/99593_All_Languages.jpg)
![](https://www.hellermanntyton.com/shared/speclogos/99595_All_Languages.jpg)
Request your individual offer now
Request quote
More products in this product group:
Application | Where speed, simplicity, and a firm fixing base are required these self adhesive clips are ideal. Particularly suitable for use in control cabinets, telecoms equipment or domestic appliances where the use of holes, screws, or nuts and bolts is impractical or undesirable. |
Colour | Natural (NA) |
Fixation Method | Screw Mounting and Adhesive |
For Ties | T18 - T40 |
Material | Polyamide 6.6 (PA66) |
PART DESCRIPTION | TY3G1S-PA66-NA |
Pack Cont. | 100pcs. |
Package Content packed in | pcs. |
Product Family | TY-Series Rectangle Design, self adhesive, screwable |
Product Group | Self Adhesive / Screw Fixing Cable Tie Mounts |
Short Description | Screw Fixing Cable Tie Mount self adhesive 20x14 natural |
Type | TY3G1S |
|
|
Country of Origin | DE |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026122168 |
Packaging 1 - Height (m) | 0.02m |
Packaging 1 - Length (m) | 0.275m |
Packaging 1 - Qty | 100 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.00066m³ |
Packaging 1 - Weight (kg) | 0.08601kg |
Packaging 1 - Width (m) | 0.12m |
Packaging 3 - Height (m) | 0.171m |
Packaging 3 - Length (m) | 0.56m |
Packaging 3 - Qty | 5000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.0172m³ |
Packaging 3 - Weight (kg) | 4.5205kg |
Packaging 3 - Width (m) | 0.18m |
Packaging 4 - Height (m) | 1.17m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 240000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.123m³ |
Packaging 4 - Weight (kg) | 239.16kg |
Packaging 4 - Width (m) | 0.8m |
