Cable tie inside serrated, 302.26x4.8mm, ∅7.0-80.0mm, black, 100pcs.
Art.-Nr. 111-01266 | GL300-PA11W-BK |  Details

Cable ties are fabricated using Polyamide 11, a material that provides excellent UV, chemical, and moisture resistance.

    • Manufactured from polyamide 11
    • High UV resistance for long-term outdoor applications
    • Stable technical performance even at very low temperatures
    • High resistance to chemicals, including chlorides
    • Low water absorption rate for consistent technical performance and high durability
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads e-Learning
    Application GalvaLok cable ties have many technical features which make them suitable for use in many applications for fixing and supporting cables, pipes and other elements. The polyamide 11 used to manufacture these ties offers excellent resistance to chemicals in even the most challenging environments such as offshore, oil rigs, construction vehicles, trucks and trailer. These cable ties have excellent UV resistance as well as being highly resistant to chemicals like chlorides: recommended for use on galvanised steel, especially on solar panel installations. In addition, the material has a high impact resistance to low temperatures which enables GalvaLok ties to be used in areas where it is cold, for example at high altitudes or Nordic countries.
    Colour Black (BK)
    Identification Plate Position none
    Material Polyamide 11, UV-resistant (PA11W)
    PART DESCRIPTION GL300-PA11W-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family Galvalok-Series in PA11 black
    Product Group Cable Ties for bundling wires in solar power systems
    Releasable Closure (Yes/No) No
    Short Description Cable Tie 301x4.8 PA11 UV-black
    Tie Closure plastic pawl
    Type GL300
    Variant Inside Serrated
    Bundle Diameter max (metric) 80.0mm
    Bundle ∅ 7.0-80.0mm
    Bundle ∅ min. 7.0mm
    Cable Tie Head Height (metric) 5.0mm
    Cable Tie Head Length (metric) 9.0mm
    Cable Tie Head Width (metric) 8.8mm
    Length (L) 302.26mm
    Min.Tensile Strength 250N
    Thickness (T) 1.5mm
    Weight/Unit 0.00218kg
    Width (W) 4.8mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Specifications IEC 62275, IEC 62275:2018, UL 62275
    UV-Stabilised Yes
    Country of Origin JP
    Customs Number 39269097
    GTIN-13 / EAN 4944387960709
    Packaging 1 - Height (m) 0.04m
    Packaging 1 - Length (m) 0.43m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00232m³
    Packaging 1 - Weight (kg) 0.218001kg
    Packaging 1 - Width (m) 0.135m
    Packaging 3 - Height (m) 0.25m
    Packaging 3 - Length (m) 0.44m
    Packaging 3 - Qty 5000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0341m³
    Packaging 3 - Weight (kg) 11.62405kg
    Packaging 3 - Width (m) 0.31m
    Packaging 4 - Height (m) 1.144m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 80000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.098m³
    Packaging 4 - Weight (kg) 206.984kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
