Cable tie inside serrated, 80x2.2mm, ∅1.0-16.0mm, natural, 1000pcs.
Art.-Nr. 114-00879
| T18S-PA46-NA
|
Details
- Available in a wide range of materials and sizes
- High tensile strength with very low insertion force
- Only high quality plastic is used meeting recycling targets
- Inside serrated cable ties for a strong hold onto bundles
- Ergonomic bent tail offers quick and simple installation
- Easy application either manually or with an application tool
Request your individual offer now
Request quote
More products in this product group:
| Application | T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications. |
| Application Method | Quick, simple fixing by hand or with HellermannTyton tensioning tools |
| Colour | Natural (NA) |
| Identification Plate Position | none |
| Material | Polyamide 4.6 (PA46) |
| PART DESCRIPTION | T18S-PA46-NA |
| Pack Cont. | 1000pcs. |
| Package Content packed in | bag |
| Product Family | T-Series in PA46 |
| Product Group | Cable Ties for temperatures up to + 195 °C (500 h) in Polyamide 4.6 |
| Releasable Closure (Yes/No) | No |
| Short Description | Cable Tie 85x2.3 mm natural |
| Tie Closure | plastic pawl |
| Type | T18S |
| Variant | Inside Serrated |
|
|
| Bundle Diameter max (metric) | 16.0mm |
| Bundle ∅ | 1.0-16.0mm |
| Bundle ∅ min. | 1.0mm |
| Cable Tie Head Height (metric) | 3.2mm |
| Cable Tie Head Length (metric) | 4.5mm |
| Cable Tie Head Width (metric) | 4.2mm |
| Height (H) | 3.2mm |
| Length (L) | 80mm |
| Min.Tensile Strength | 80N |
| Strap Width max. (G) | 0.17" |
| Thickness (T) | 1.0mm |
| Weight/Unit | 0.000213kg |
| Width (W) | 2.2mm |
Download
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 V2 |
| Hazardous Goods | No |
| Limited Fire Hazard | Yes |
| Nato number | 5975-12-372-9909 |
| Operating Temperature | -40 °C to +130 °C |
| ROHS compliant | Yes |
| Specifications |
|
| Specifications | ANSI/UL 1565, ANSI/UL 62275 |
| UL OCD link | Link |
| UL Recognized (US) | Yes |
| UL-File Number | E64962 |
| UV-Stabilised | No |
|
|
|
| Country of Origin | JP |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026108308 |
| Packaging 1 - Height (m) | 0.04m |
| Packaging 1 - Length (m) | 0.185m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00196m³ |
| Packaging 1 - Weight (kg) | 0.213kg |
| Packaging 1 - Width (m) | 0.265m |
| Packaging 3 - Height (m) | 0.345m |
| Packaging 3 - Length (m) | 0.455m |
| Packaging 3 - Qty | 50000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0494m³ |
| Packaging 3 - Weight (kg) | 11.09kg |
| Packaging 3 - Width (m) | 0.315m |
| Packaging 4 - Height (m) | 1.179m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 750000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.132m³ |
| Packaging 4 - Weight (kg) | 187.35kg |
| Packaging 4 - Width (m) | 0.8m |
