Fixing tie for edge, inside serrated, ∅1.0-32.0mm, black, 500Set
Art.-Nr. 156-00959 | T30REC10SDSET-PA66HS/PA66HIRHS-BK |  Details

T50ROSEC10 fitted onto a plastic panel to hold a Ø 6 mm harness.

    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP
    Colour Black (BK)
    Content 500 T30R + 500 EC10SD
    Identification Plate Position none
    Key product features for narrow bundling
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T30REC10SDSET-PA66HS/PA66HIRHS-BK
    Pack Cont. 500Set
    Package Content packed in bag
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T30REC10SDSET
    Variant Inside Serrated
    Bundle Diameter max (metric) 32.0mm
    Bundle ∅ 1.0-32.0mm
    Bundle ∅ min. 1.0mm
    Height (H) 1.1mm
    Height (H2) 12.0mm
    Length (L) 150.0mm
    Length (L2) 15.0mm
    Min.Tensile Strength 135N
    Width (W) 3.6mm
    Width (W2) 11.0mm
    for Panel Thickness min - max 1 - 3 mm
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026449845
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121731
    Show all
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...
