31/10/2024

Fixing tie with pipe/tube holder, inside serrated, ∅27.0-50.0mm, black, 500Set
Art.-Nr. 156-00126 | T50RIAHC4TSET-PA66HS/PA66HIRHS-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application These 2-piece ties are a quick and easy method of fixing and bundling cables. Originally developed for the automotive industry.
    Colour Black (BK)
    Content 500 T50 + 500 IAHC4T
    Fixation Method Omega Clip
    Identification Plate Position none
    Key product features lockable, rotatable
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T50RIAHC4TSET-PA66HS/PA66HIRHS-BK
    Pack Cont. 500Set
    Package Content packed in pcs.
    Product Family IAHC-Series
    Product Group 2-Piece Fixing Ties with Automatic Harness Clip, connectable and twistable 360°
    Releasable Closure (Yes/No) No
    Short Description 2 piece fixing tie with T50R and fixing element 360 degrees turnable
    Tie Closure plastic pawl
    Type T50RIAHC4TSET
    Variant Inside Serrated
    Attach to Ø 27.0 - 36.0 mm
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ 27.0-50.0mm
    Bundle ∅ min. 27.0mm
    Weight/Unit 0.0097kg
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin FR
    Customs Number 39269097
    GTIN-13 / EAN 4031026264929
    Packaging 1 - Height (m) 0.2m
    Packaging 1 - Length (m) 0.46m
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.04784m³
    Packaging 1 - Weight (kg) 0.0448kg
    Packaging 1 - Width (m) 0.52m
    Packaging 3 - Height (m) 0.204m
    Packaging 3 - Length (m) 0.591m
    Packaging 3 - Qty 500
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.048m³
    Packaging 3 - Weight (kg) 5.5kg
    Packaging 3 - Width (m) 0.398m
    Packaging 4 - Height (m) 1.164m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 10000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.117m³
    Packaging 4 - Weight (kg) 131.0kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121731
    Show all
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...
