Fixing tie for hole (oval), ∅1.6-50.0mm, black, 1000
Art.-Nr. 156-04089 | T50ROSATSFT6SO25A-PA66HS/PA66HIRHS-BK |  Details

These fir tree fixings can also be used in threaded, blind holes.

    • Pre-assembled 2-piece fixing tie with fir tree foot part
    • Cable tie head can be moved after bundling
    • Easy to assemble without the need for a tool
    • Disc adjusts tie for pressure from various directions and minimises access of dust, dirt and water
    • Fir tree foot part can be used for a variety of panel thicknesses
    • Suitable for use within threaded holes
    • DOP versions for oval holes feature anti-twist protection
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
    Colour Black (BK)
    Fixation Method Fir Tree
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T50ROSATSFT6SO25A-PA66HS/PA66HIRHS-BK
    Pack Cont. 1000
    Package Content packed in bag
    Product Family 2-Pieces Fixing Ties with Fir Tree, with Disc, for Oval Holes
    Product Group 2-Pieces Fixing Ties with Fir Tree, with Disc
    Tie Closure plastic pawl
    Type T50ROSATSFT6SO25A
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ 1.6-50.0mm
    Bundle ∅ min. 1.6mm
    Length (L) 198.0mm
    Min.Tensile Strength 225N
    Panel Thickness max. 0.6-6.65mm
    Thickness (T) 1.3mm
    Width (W) 4.6mm
    Width (W2) 19.0mm
    for Hole ∅ (FH) 6.3 - 6.7 mm, 6.1 - 6.6 mm (hexagonal)
    for Panel Thickness min - max 0.6 - 6.7 mm
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026671598
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
