Fixing tie for edge/for cable bundles, outside serrated, ∅2.0-50.0mm, black, 500pcs.
Art.-Nr. 156-03291
| T50ROSDEC1.5-4SP-PA66HS/PA66HIRHS-BK
|
Details
- Pre-assembled 3-piece fixing tie with EdgeClip
- For parallel routing of two harnesses
- For minimum bundle diameters of 2 mm
- For edges of 1.5 – 4 mm
Request your individual offer now
Request quote
| Application | These cable ties and EdgeClip assemblies are ideal for parallel routing use where holes are not acceptable or where due to temperature problems adhesives will fail. These assemblies are widely used for fixing and bundling cables, pipes and hoses within the automotive industry, harness making, panel building and electrical industry. |
| Cable Tie | Polyamide 6.6, heat stabilised (PA66HS) |
| Colour | Black (BK) |
| Description | 3-piece fixing tie, EdgeClip 1.5 - 4 mm, for parallel routing |
| Fixation Method | EdgeClip, sideway, assembled, 2 piece |
| Foot Part | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Identification Plate Position | none |
| Key product features | for multiple routing |
| Material | Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | T50ROSDEC1.5-4SP-PA66HS/PA66HIRHS-BK |
| Pack Cont. | 500pcs. |
| Package Content packed in | bag |
| Releasable Closure (Yes/No) | No |
| Short Description | 3-Piece Fixing Tie, outside serrated 200x4.6 for Edges 1.5-4 mm, for parallel routing, HS/HIRHS-black |
| Tie Closure | plastic pawl |
| Type | T50ROSDEC1.5-4SP |
| Bundle Diameter max (metric) | 50.0mm |
| Bundle ∅ | 2.0-50.0mm |
| Bundle ∅ min. | 2.0mm |
| Cable Tie Head Height (metric) | 5.9mm |
| Cable Tie Head Length (metric) | 6.75mm |
| Cable Tie Head Width (metric) | 7.9mm |
| Height (H) | 1.3mm |
| Height (H2) | 16.1mm |
| Length (L) | 200.0mm |
| Length (L2) | 15.0mm |
| Min.Tensile Strength | 225N |
| Panel Thickness max. | 1.5 - 4.0mm |
| Thickness (T) | 1.3mm |
| Weight/Unit | 0.004681kg |
| Width (W) | 4.6mm |
| Width (W2) | 15.8mm |
| for Panel Thickness min - max | 1.5 - 4 mm |
Download
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026734620 |
| Packaging 1 - Height (m) | 0.07m |
| Packaging 1 - Length (m) | 0.55m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0181m³ |
| Packaging 1 - Weight (kg) | 2.384097kg |
| Packaging 1 - Width (m) | 0.47m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 2500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 12.740485kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 30000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 173.91kg |
| Packaging 4 - Width (m) | 0.8m |
