Fixing tie for hole (round), inside serrated, ∅1.5-44.0mm, black, 1000pcs.
Art.-Nr. 126-01005 | T50RSF(U)-PA66HIRHSUV-BK |  Details

The arrowhead design allows these fixing ties to be used in areas with limited space.

    • Easy to assemble without the need for a tool
    • Fixing tie with arrowhead without wings
    • Arrowhead simply locks into place
    • Cable tie head always situated in defined position
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The arrowhead design is usefull in areas with limited space.
    Colour Black (BK)
    Fixation Method arrowhead
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T50RSF(U)-PA66HIRHSUV-BK
    Pack Cont. 1000pcs.
    Package Content packed in bag
    Product Family without wings and disc, for round holes
    Product Group 1-Piece Fixing Ties with Arrowhead
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50RSF(U)
    Variant Inside Serrated
    Bundle Diameter max (metric) 44.0mm
    Bundle ∅ 1.5-44.0mm
    Bundle ∅ min. 1.5mm
    Height (H) 7.5mm
    Length (L) 210mm
    Min.Tensile Strength 225N
    Panel Thickness max. 1.0 – 3.5mm
    Thickness (T) 1.2mm
    Width (W) 4.7mm
    for Hole ∅ (FH) 6.4 - 7.1 mm
    for Panel Thickness min - max 1 - 3.5 mm
    for Panel Thickness min - max 0 - 0.1 "
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UV-Stabilised Yes
    Country of Origin MX
    GTIN-13 / EAN 4031026687421
    Packaging 3 - Height (m) 0.20955m
    Packaging 3 - Length (m) 0.60801m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0506m³
    Packaging 3 - Width (m) 0.39688m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
