Fixing tie for hole (oval), ∅1.5-25.0mm, black, 500pcs.
Art.-Nr. 126-00371 | T60XSOSSFT712-E-MD2-PA66HS-BK |  Details

Fixing bracket for an oval hole with a seal for protection against e.g. dust and splash water.

    • Easy to assemble without the need for a tool
    • Arrowhead simply locks into place
    • Disc adjusts the tie for pressures from various directions
    • Cable tie head always situated in defined position
    • Cellular rubber seal minimises access of dust and dirt
    • SFT versions for oval holes feature anti-twist protection
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The parts are mainly used in the automotive industry, e.g. for door harnesses.
    Colour Black (BK)
    Fixation Method Arrowhead for oval holes
    Identification Plate Position none
    Key product features sealed
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION T60XSOSSFT712-E-MD2-PA66HS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family for oval holes, sealed
    Product Group 1-piece fixing ties with arrowhead, with disc
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T60XSOSSFT712-E-MD2
    Bundle Diameter max (metric) 25.0mm
    Bundle ∅ 1.5-25.0mm
    Bundle ∅ min. 1.5mm
    Disc ∅ 16 x 22mm
    Weight/Unit 0.00198kg
    for Hole ∅ (FH) 7.0 x 12.0 mm
    for Panel Thickness min - max 0.6 - 1.6 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    Customs Number 39269097
    GTIN-13 / EAN 4031026638225
    Packaging 3 - Height (m) 0.21m
    Packaging 3 - Length (m) 0.575m
    Packaging 3 - Qty 2000
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0465m³
    Packaging 3 - Weight (kg) 4.8kg
    Packaging 3 - Width (m) 0.385m
    Packaging 4 - Height (m) 1.194m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 40000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.146m³
    Packaging 4 - Weight (kg) 117.0kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
