Connector clip, black, 6000pcs.
Art.-Nr. 151-03002 | CC11SFT712-PA66HIRHS-BK |

Copied

    • Connector clips provide a single method to mount connectors to various surfaces in a variety of applications.
    • Highly engineered designs feature anti-rattle discs, anti-rotation oval fir trees and clamps for mounting on edges.
    • A wide assortment of styles is available to fit the variety of connector slot designs made by most of the largest global connector manufacturers.
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CC11SFT712-PA66HIRHS-BK
    Pack Cont. 6000pcs.
    Package Content packed in bag
    Type CC11SFT712
    Height (H) 14.2mm
    Length (L) 27.2mm
    Panel Thickness max. 1.8-2.8mm
    Width (W) 17.4mm
    for Hole ⌀ (FH) 7.0 x 12.0 mm
    for Panel Thickness min - max 1.8 - 2.8 mm
    Country of Origin CN
    GTIN-13 / EAN 4031026627663
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 31162305
