Connector clip for connector/for hole (round), black, 500pcs.
Art.-Nr. 151-01337 | CC2SFT7-MD-PA66HIRHS-BK |  Details

    • Connector easily installed by simply pushing into place
    • Connection can be released (non-destructive)
    • Arrowhead locks into place for secure fixing at all times
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The connector clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement.
    Colour Black (BK)
    Key product features sealed
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CC2SFT7-MD-PA66HIRHS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Family With Arrowhead
    Product Group Connector Clips for round holes, sealed
    Type CC2SFT7-MD
    Length (L) 18.0mm
    for Hole ∅ (FH) 6.8 - 7.2 mm
    for Panel Thickness min - max 0.7 - 2 mm
    Country of Origin CN
    GTIN-13 / EAN 4031026515588
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121702
