Connector clip for hole (round), EWCAP-005-7, black, 5000pcs.
Art.-Nr. 151-00785
| CCFT6LG-PA66HIRHS-BK
|
Details
- Connector easily installed by simply pushing into place
- Connection can be released (non-destructive)
- One fir tree foot part can be used for a variety of panel thicknesses
- Disc covers the hole to prevent dirt and water gaining access
- For twist protection: Variants with additional stick or for oval holes
Request your individual offer now
Request quote
More products in this product group:
| Application | The connector clips used here have been designed for electronic cables and cable sets used in the automotive industry. |
| Colour | Black (BK) |
| Fixation Method | Fir tree for round holes |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | CCFT6LG-PA66HIRHS-BK |
| Pack Cont. | 5000pcs. |
| Package Content packed in | bag |
| Product Group | Connector Clips for round holes |
| Short Description | Connector Clip, round hole 6.0 - 6.7 mm, fir tree, high impact modified, heat stabilised, black |
| Type | CCFT6LG |
| Variant | 6.1 - 6.9 mm |
Download
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | No |
|
|
|
| Country of Origin | FR |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026326894 |
| Packaging 1 - Qty | 5000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Weight (kg) | 3.245kg |
| Packaging 3 - Height (m) | 0.171m |
| Packaging 3 - Length (m) | 0.56m |
| Packaging 3 - Qty | 5000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0172m³ |
| Packaging 3 - Weight (kg) | 3.465kg |
| Packaging 3 - Width (m) | 0.18m |
| Packaging 4 - Height (m) | 1.17m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 240000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.123m³ |
| Packaging 4 - Weight (kg) | 187.32kg |
| Packaging 4 - Width (m) | 0.8m |
