MOQ is 26.000 pcs.

Cable clip, T=1.8 - 2.25mm, ⌀13.0 - 15.0 mm, Dmin=4.9mm, Dmax=7.3mm
Art.-Nr. 151-00899 | HC2x7.3AH13-PV-PA66W-BK |  Details

Deploying the mounting rail C-channel for fixing elements.

    • Click wires into clip to be held securely in place
    • 360° rotatable clip, this allows movement of wires if needed
    • Just push the arrowhead into place for very quick and simple fixing
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Offering a simple and secure method of attaching cables to panels. Originally designed for the automotive industry they are finding a wide variety of applications in all industries using sheet metal panels.
    Colour Black (BK)
    Fixation Method with Arrowhead / Push Mount (Mounts)
    Internet Customer Notice MOQ is 26.000 pcs.
    Material Polyamide 6.6, UV-resistant (PA66W)
    PART DESCRIPTION HC2x7.3AH13-PV-PA66W-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family Harness Clip with arrowhead
    Product Group Fixing Elements for Tubes and Harnesses
    Short Description harness clip for parallelrouting PA66W black
    Type HC2x7.3AH13-PV
    Bundle ⌀ 4.9-7.3mm
    Bundle ⌀ min. 4.9mm
    Bundle Diameter max (metric) 7.3mm
    Height (H2) 30.9mm
    Length (L) 26.4mm
    Panel Thickness max. 1.8 - 2.25mm
    Weight/Unit 0.0031kg
    Width (W) 24.0mm
    for Hole ⌀ (FH) 13.0 - 15.0 mm
    for Panel Thickness min - max 1.8 - 2.3 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C, (+105 °C, 500 h)
    ROHS compliant Yes
    Specifications
    Country of Origin PL
    Customs Number 39269097
    GTIN-13 / EAN 4031026432410
    Packaging 1 - Height (m) 0.15m
    Packaging 1 - Length (m) 0.3m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.0117m³
    Packaging 1 - Weight (kg) 0.323862kg
    Packaging 1 - Width (m) 0.26m
    Packaging 3 - Height (m) 0.204m
    Packaging 3 - Length (m) 0.591m
    Packaging 3 - Qty 2000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.048m³
    Packaging 3 - Weight (kg) 7.12724kg
    Packaging 3 - Width (m) 0.398m
    Packaging 4 - Height (m) 1.164m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 40000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.117m³
    Packaging 4 - Weight (kg) 163.6kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 31162305
